Geo Square Fire Table in GFRC Concrete by Archpot
The Geo Square Fire Pit comes in different sizes. The largest size certainly qualifies as a table with its beefy ledge, and the other two have a sleeker lip. Pair the smaller ones up to create a unique outdoor experience.
The Electronic AWEIS (All Weather Electronic Ignition System) Ignition by Fire by design is an excellent upgrade to the Match-Lit version. The controls are simple and easy to use. To ignite the table, simply push the electronic start button on the access panel or optional remote, and the fire effortlessly starts. This system is specifically designed to keep your fire feature lit and will automatically re-light if the flame is blown out. The system will also automatically shut off if the flame can not be re-lit.
All Weather Electronic Ignition System UPGRADE is available for all burner options.
- AWEIS Control Box (24V AC or 30V DC)
- Thermal Sensing Pilot Burner
- 24V AC or 30V DC Transformer (24V AC or 30V DC)
- Natural Gas or Propane (please specify)
- LC Certification
- Links to Pool Operating Systems
Options for Electronic Ignitions:
- Bluetooth Remote
- Electrical Dial Timer
- Emergency Shut-off Button (E-Stop)
- Safety Tower Post with Electrical Timer and E-Stop
Specifications:
| SKU |
Length |
Width |
Height |
Base |
Support Plate |
Burner/BTU |
Weight |
| FGGSQ42X18-FT |
42" |
42" |
18" |
24.25" Sq. |
26.25" Sq. |
316 SS 18”/ 136K BTU
CrossFire 15"/ 180K BTU
|
290 lbs |
| Propane Enclosure Kit |
18" |
18" |
20" |
N/A |
N/A |
N/A |
220 lbs |
Burner Options: All Weather Electronic Ignition System UPGRADE is available for all burner options.
|
Burner Options
|
Details
|
|
316 Stainless Kit
|
- 316 Marine Grade Stainless Steel Spiral Burner
- Weather Resistant Stainless Steel Burner
- BTU varies by size
- 12 Gauge 304 Stainless Steel Support Plate
- Key Valve Assembly
- Whistle-Free Flex Line x2
- Natural Gas or Propane (please specify)
- Available in Manual or Electronic ignition
|
|
CROSSFIRE Brass Kit
|
- Cross Fire Brass Octagonal Burner
- BTU varies by size
- 12 Gauge 304 Stainless Steel Support Plate
- Key Valve Assembly
- Whistle-Free Flex Line x2
- Natural Gas or Propane (please specify)
- Available in Manual or Electronic ignition
|
The Geo Square and Rectangle Series comprises the following:
Geo Square Fire Bowl
Geo Square Fire & Water Bowl
Geo Square Water Bowl
Geo Square Planter Water Bowl
Geo Slender Square Vase Planter
Geo Square Fire Table and Geo Rectangle Fire Table
Geo Square Planter, Geo Tall Square Planter, Geo Rectangle Planter, and Geo Low Square Planter
Material
Glass-fiber reinforced concrete (GFRC)
GFRC Process
Concrete bowls incorporate a concrete-glass fibre mix, resulting in a lighter but structurally stronger bowl. These decorative pieces are beautifully finished with a hand-applied process that includes multiple stains and washes and includes a final wax seal. The wax seal provides a deep, lustrous finish and protection against fading and discoloration from the outdoor environment. The wax seal requires direct sunlight to finish the curing process. Paint and quick drying cures are not used as this would sacrifice the quality and beauty of the finished products.
Product Manuals:
24V AWEIS Manual
PDF Manual System Install Guide
IMPORTANT: Installation must be done by a Licensed Technician.
Warranty: 1 year against manufacturing defects.
Shipping: We offer Free standard shipping on all our products. Usually ships on a pallet to any address in the Continental USA. The carrier will place your items curbside on your property but cannot assist with final placement. A Lift-gate charge may be applied for residential deliveries.
Manufacturing Lead Time: This is a Made-To-Order item, manufactured in the color specified on your order. The Manufacturing Lead time is approx 10 weeks.
Disclaimer:This Product is considered a Custom Order as it is custom made upon order. The Patina/ Stain chosen is hand applied to the Product along with finishing touches after it is manufactured in accordance with your order. The cancellation of a custom product will result in the forfeiture of the deposit.
Prop 65 Warning: For more information, go to www.P65Warnings.ca.gov.
